| Projection System |
| Projection System |
DLP |
| Display |
| Brightness (ANSI lumens) |
4000 |
| Native Resolution |
WUXGA (1920x1200) |
| Native Aspect Ratio |
16:10 |
| Contrast Ratio (FOFO) |
10,000:1 |
| Display Color |
30 Bits (1,07 billion colors) |
| Light Source |
Lamp |
| Light Source Life |
a. Normal 4000 hrs, b. ECO 10000 hrs, c. SmartEco 8000 hrs, d. LampSave 15000 hrs |
| Optical |
| Throw Ratio |
1.5~1.65 |
| Zoom Ratio |
1.1x |
| Lens |
F/#=2.0~2.05;f=15.843~17.445 mm |
| Projection Offset (Full-Height) |
100 % |
| Keystone Adjustment |
1D, Vertical ± 40 degrees |
| Picture |
| Rec. 709 Coverage |
83% |
| Picture Modes |
3D, Bright, Infographic, Presentation, sRGB, Vivid |
| Compatibility |
| Input Lag |
2 frame (33.34ms) 60Hz |
| Resolution Support |
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking |
| Horizontal Frequency |
15K~102KHz |
| Vertical Scan Rate |
23~120KHz |
| I/O Interface |
| PC in (D-sub 15pin) |
(x1) |
| Monitor out (D-sub 15pin) |
(x1) |
| HDMI in |
(x2) , HDMI-1 (1.4a/HDCP1.4), HDMI-2 (1.4a/HDCP1.4) |
| USB Type A |
(x1) , USB Type A-1 (2.0/Power Supply1.5A) |
| RS232 in (DB-9pin) |
(x1) |
| Audio0 |
| Speaker |
(x1) , 2W |
| Audio in (3.5mm Mini Jack) |
(x1) , 1 |
| Audio out (3.5mm Mini Jack) |
(x1) , 1 |
| Environment |
| Operating Temperature |
0~40℃ |
| Power Supply |
AC 100 to 240 V, 50/60 Hz |
| Typical Power Consumption (110V) |
260W/110V |
| Acoustic Noise (Typ./Eco.)(dB) |
34/29 |
| Accessories |
| Remote Control w/ Battery |
RCX014 |
| Power Cord (by region) |
x1 (1.8M) |
| VGA (D-sub 15pin) Cable |
(Standard), 1 (1.5m) |
| 3D Glasses |
(Optional), DGD5 |
| Quick Start Guide |
1 (21L) |
| Dimension & Weight |
| Dimensions (WxHxD) (mm) |
312 x 225 x 110 |
| Net Weight (kg) |
2.79 +/- 0.1 kg |
| Warranty |
| Warranty |
ระยะเวลารับประกัน (ตัวเครื่อง) : 3 ปี |
| |
ระยะเวลารับประกัน (หลอดฉาย) : 12 เดือน /1000 ชั่วโมง หรืออย่างใดอย่างหนึ่งที่ครบกาหนดก่อน |
